Specifications *
- Effective ADC bits (without error): 8 bits
- Min sampling rate: 1500 Sa/s
- Max sampling rate (2 channels): 100 MSa/s
- Input range: ±100mV to ±5V
- Number of samples each scan: up to 65KSa / channel
- Waveform update rate (2 channels): up to 30 wfms/sec
- Roll Mode: supported
- AC/DC: hardware
- Trigger: hardware just on CH1
Models Supported
For Loto OSCA02, all the submodels are supported, including the M one which is provided with its own Android app:
OSCA02, OSCA02M, OSCA02S, OSCA02X, OSCA02E, OSCA02ML, OSCA02F, OSCA02L, OSCA02H
Submodels are just supported in the main Oscilloscope features and not in the specific additional feature (for example signal generator).
Modules Support
- Automotive Module: SUPPORTED (up to 125KSa/s real-time)
- Audio Module: SUPPORTED
- FX2 Experimental Mode: SUPPORTED (Automotive Module up to 250KSa/s real-time)
Advantages
- Hardware AC/DC coupling
- Fast real time acquisition with Cypress FX2 chipset (reach top rate in Automotive Module)
- High ADC resolution at lower rates
- Long memory buffer (65K samples / channel)
- Hardware Trigger
- HScope can read calibration data in the oscilloscope (not need to be calibrated)
Disadvantages
- ±Input voltage up to 5V
- Can use the trigger just on Channel 1
Loto OSC2002
Loto OSC2002 is recognized and supported in HScope as the OSCA02. Sampling rate in HScope up to 100MSa/s.
Resources
- Loto OSCA02 Vendor Website
- Loto OSC2002 Vendor Website
- Official Software & Drivers
* This information is valid just within HScope, it may not reflect the Manufacturer information
